15mK Ultra Clear Image
Equipped with a high-sensitivity thermal detector (NETD ≤15mK), the Oryx-L captures even the smallest temperature differences, delivering sharper, more detailed images regardless of challenging weather conditions.
Unparalleled Clarity and Details
Experience unparalleled clarity and detail with the high-end 2560×2560 resolution 1.03” OLED display. Designed for comfort, it reduces visual fatigue from long-time observation.
Innovative Built-in LRF Module
Equipped with built-in LRF module, Oryx-L ensures laser range-finding up to 1200 meters, ensuring precise distance measurements while maintaining a sleek and elegant design.
8 Hours Continuous Operation
Offer up to 8 hours of runtime on a 21700 replaceable battery, even with its high-resolution 2560×2560 OLED display. The horizontal placement keeps your view clear and adds a sleek, day scope-like look.
ThermTec AutoSight System（TASS）
Auto switch to base magnification for the widest field of view after a high-magnification shot to keep your target firmly in sight. No more manual switching to slow you down; the Oryx-L ensures you stay on top of the action
Consistently Clear & Stable Image
ThermTec AI calibration with shutterless image system reduces shutter frequency, minimizing image freezing and ensuring stable and consistent images over changing environments.
Accurate Long-Range Shooting
Powered by the built-in LRF module, Oryx-L accurately measures distances up to 1200 meters, ensuring fast, informed targeting decisions for optimal hunting experience for long-range shooting.
More Advantage
2600m Long Detection Range
Al Calibration Enhanced Image Stability
1200m Long Detection Range
Central Turret Focus
Large 1.03 2560×2560 OLED
Recoil Activated Video
Silent Lens Cover
Download
Specifications
Oryx-L 635
Oryx-L 650
Oryx-L 635
| Type | Uncooled |
| Resolution | 640×512 |
| Pixel pitch | 12µm |
| NETD | ≤15mK |
| Spectral range | 8-14µm |
| Frame rate | 50Hz |
| Detection range | 1800m |
| Objective lens | 35mm, F0.8 |
| Field of view | 12.5°× 10 ° |
| / m @100m | 21.9×17.6 |
| Magnification | 2.6x |
| Digital zoom | 1x-4x |
| Eye relief | 60mm |
| Exit pupil | 6mm |
| Diopter | ±5D |
| Reticle | 7 |
| Reticle color | 6 |
| Display resolution | 2560×2560 |
| Display size | 1.03 inch |
| Color palette | 6 |
| Max. recoil power on rifled weapon | 6000J |
| Mounting brackets on weapon | Standard 30mm rings |
| RAV | Yes |
| Audio recording | Yes |
| Manual zeroing | Yes |
| Zeroing profiles | 6 |
| Freeze zeroing | Yes |
| Picture-in-picture | Yes |
| Laser ranging | 1200m |
| Ballistic calculator | Yes |
| Image calibration | Manual/Auto |
| Photo/video playback | Yes,1280*1024 |
| Inbuilt memory | 64GB |
| Type C | Data transfer， Battery charge |
| Hotspot | Yes |
| Battery type | Replaceable, 1*21700，6000mAh |
| Battery life | 8h |
| Operating temperature | -20°C to +50°C |
| IP rating | IP67 |
| Weight, g | 1050±5 |
| Size, mm | 385(L)x93(W)x77(H)±5 |
Oryx-L 650
| Type | Uncooled |
| Resolution | 640×512 |
| Pixel pitch | 12µm |
| NETD | ≤15mK |
| Spectral range | 8-14µm |
| Frame rate | 50Hz |
| Detection range | 2600m |
| Objective lens | 50mm, F0.9 |
| Field of view | 8.8° × 7.0 ° |
| / m @100m | 15.4×12.3 |
| Magnification | 3.7x |
| Digital zoom | 1x-4x |
| Eye relief | 60mm |
| Exit pupil | 6mm |
| Diopter | ±5D |
| Reticle | 7 |
| Reticle color | 6 |
| Display resolution | 2560×2560 |
| Display size | 1.03 inch |
| Color palette | 6 |
| Max. recoil power on rifled weapon | 6000J |
| Mounting brackets on weapon | Standard 30mm rings |
| RAV | Yes |
| Audio recording | Yes |
| Manual zeroing | Yes |
| Zeroing profiles | 6 |
| Freeze zeroing | Yes |
| Picture-in-picture | Yes |
| Laser ranging | 1200m |
| Ballistic calculator | Yes |
| Image calibration | Manual/Auto |
| Photo/video playback | Yes,1280*1024 |
| Inbuilt memory | 64GB |
| Type C | Data transfer， Battery charge |
| Hotspot | Yes |
| Battery type | Replaceable, 1*21700，6000mAh |
| Battery life | 8h |
| Operating temperature | -20°C to +50°C |
| IP rating | IP67 |
| Weight, g | 1100±5 |
| Size, mm | 397(L)x87(W)x74(H) |
