VENTUS 635L
VENTUS 650L
VENTUS 635L
| Thermal Module Resolution | 640×512 |
| Pixel pitch | 12μm |
| NETD | ＜15mK@300K |
| Spectral range | 8-14μm |
| Objective lens | 35mm/F0.9 |
| Field of View/m@100m | 12.5°×10° / 21.9×17.6 |
| Frame rate | 50Hz |
| Magnification | 2.6X-10.4X(4X) |
| Detection range | 1800m |
| Objective lens | 3536×3536，2μm |
| Field of view/m@100m | 8.1°×8.1° / 14.14×14.14 |
| Objective lens | 50mm/F1.4 |
| IR illuminator wavelength | 850nm/940nm switchable |
| Viewing range at night | 850nm: 400m/940nm:350m |
| Magnification | 4X-16X(4X) |
| Type | AMOLED |
| Image Display Resolution | 1600×1200 |
| Display size | 0.5 inch |
| Color palette | 6 |
| EIS | Yes |
| Eye relief | 20mm |
| Exit pupil | 8mm |
| Diopter | ±5D |
| Interpupillary adjustment range | 60 mm to 72 mm |
| Image mode | Forest/Rainy |
| TSR algorithm | Yes |
| Safety class | Class 1 |
| Wavelength | 905nm |
| Range | 1000m |
| Accuracy | ±1m |
| Photo/Video playback | Yes |
| Audio recording | Yes |
| Azimuth | Yes |
| Digital magnetic compass | Yes |
| Hotspot | Yes |
| Language | Multiple-language |
| Storage | 64GB EMMC |
| PIP | Yes |
| Heat track | Yes |
| Local album | Yes |
| OSD recording | Yes |
| Burn prevention | Yes |
| Internal battery | Replaceable Li-ion battery (18650*2) |
| Type-C power supply | Data transfer |
| Battery life | 6h |
| Working temperature | -20℃-+50℃ |
| Protection level | IP67 |
| Weight, g | 825 |
| Size, mm | 164(L)x127.6(W)x73(H) |
| Mounting adapter | 1/4-20-UNC |
VENTUS 650L
| Thermal Module Resolution | 640×512 |
| Pixel pitch | 12μm |
| NETD | ＜15mK@300K |
| Spectral range | 8-14μm |
| Objective lens | 50mm/F1.0 |
| Field of View/m@100m | 8.8°× 7.0° / 15.4×12.3 |
| Frame rate | 50Hz |
| Magnification | 3.7X-14.8X(4X) |
| Detection range | 2600m |
| Objective lens | 3536×3536, 2μm |
| Field of view/m@100m | 8.1°×8.1° / 14.14×14.14 |
| Objective lens | 50mm/F1.4 |
| IR illuminator wavelength | 850nm/940nm switchable |
| Viewing range at night | 850nm: 400m/940nm:350m |
| Magnification | 4X-16X(4X) |
| Type | AMOLED |
| Image Display Resolution | 1600×1200 |
| Display size | 0.5 inch |
| Color palette | 6 |
| EIS | Yes |
| Eye relief | 20mm |
| Exit pupil | 8mm |
| Diopter | ±5D |
| Interpupillary adjustment range | 60 mm to 72 mm |
| Image mode | Forest/Rainy |
| TSR algorithm | Yes |
| Safety class | Class 1 |
| Wavelength | 905nm |
| Range | 1000m |
| Accuracy | ±1m |
| Photo/Video playback | Yes |
| Audio recording | Yes |
| Azimuth | Yes |
| Digital magnetic compass | Yes |
| Hotspot | Yes |
| Language | Multiple-language |
| Storage | 64GB EMMC |
| PIP | Yes |
| Heat track | Yes |
| Local album | Yes |
| OSD recording | Yes |
| Burn prevention | Yes |
| Internal battery | Replaceable Li-ion battery (18650*2) |
| Type-C power supply | Data transfer |
| Battery life | 6h |
| Working temperature | -20℃-+50℃ |
| Protection level | IP67 |
| Weight, g | 833 |
| Size, mm | 164(L)x127.6(W)x73(H) |
| Mounting adapter | 1/4-20-UNC |
